MULTIMISTER

MMS

Electric Powered Multimisting Pump Station for high capacity misting and fogging hoses assemblies.

JET NOZZLE

x2 high-performance nozzles for jet misting of fogging.

TILTING MAST

Heavy-duty mast with 0-60° vertical tilt and 340°horizontal positioning. Flat storage position for safe transporting.

EASY TO USE

Simple control operation to start/stop pump and move jet automatically from left to right. Emergency stop and warning signals.

MANOEUVRABLE

Lifting eyes and four way fork skid frame will position your JetMister into difficult locations.

REMOTE CONTROL

Control JetMisters from 100m away.

DIESEL WATER COOLED

Kubota water-cooled (HVO) diesel engine with electric start and dry run protection.

Product Specification

JM40-D
Engine / Motor
Electric Connection
Fuel Type
Fuel Tank Size - Ltr (USG)
Fuel Consumption Ltr/Hr (USG/Hr)
Emissions Standard
Power - Kw (HP)
Pressure - Bar (PSI)
Flow Rate - LPM (USGPM)
Number of Nozzles
Ave Mist water Droplet Size
Dimensions (LxWxH) - mm (inch)
Weight - Kg (Lbs)
Mist Distance (With Breeze) - M (Ft)
Horizontal Oscillation
Vertical Tilt
Generator Power Required - Kva
Std Mist Hose Length - M (Ft)
Max Water Feed Pressure - Bar (PSI)
Warrentee Period
Crane Lift Facility
Fork Lift Facility
Water Quality
Yamar L100
N/A
Diesel (HVO)
5.4 (1.5)
1 Ltr (0.25G)
Stage V
6.8 (9)
60 (870)
40 (10)
1
200-250 μm
1220 x 870 x 1230–2190
48” x 34” x 48-86”
250kg / 550lbs
15-35m / 50-115 ft
45° & 90°
0° - 45°
No
60m (195 Ft) at 1m (3Ft) Nozzle space
120m (290 Ft) @ 2m (6Ft) Nozzle space
3 Bar (43)
12 months
Yes
No
Drinking Water Quality
